Paper Title:
Development of Surface Image Scanning Device Measurement Head Mechanism Based on AFM
  Abstract

For the measurement of ultra smooth surface topography, a surface image scanning device measurement head mechanism based on the principle of atomic force microscope (AFM) was designed. It uses coarse adjustment, semi-delicate adjustment, delicate adjustment triple-stage adjustment mechanism, and tests the atomic force between the sample and the probe by using laser generator, position sensitive detector (PSD), cantilever and probe. This mechanism has high setting accuracy and resetting accuracy, combined with two-dimension movable table, can scan the surface topography of samples.

  Info
Periodical
Edited by
Kai Cheng, Yingxue Yao and Liang Zhou
Pages
828-832
DOI
10.4028/www.scientific.net/AMM.10-12.828
Citation
L. Zhou, H.B. Zhang, Q. Liu, "Development of Surface Image Scanning Device Measurement Head Mechanism Based on AFM", Applied Mechanics and Materials, Vols. 10-12, pp. 828-832, 2008
Online since
December 2007
Export
Price
$32.00
