Paper Title:
Design of Shield Hydraulic Support with Variable Parameters
  Abstract

This paper builds the design platform for the shield hydraulic support with variable parameters.The platform characterizes the following aspects: support’s mechanical modeling, the whole and parts designing,strength checking. With the aid of VC++ software development environment, the mechanical model with variable parameters is set up and the support design is carried on,including design and check of the whole support and its components,such as top beam,shielding beam,the baseboard and so on. The development of this software could shorten the research and development periods of supports with similar structures and provide the research and development platform for the support design.

  Info
Periodical
Chapter
Chapter 3: Advanced Manufacturing Technology (1)
Edited by
Dongye Sun, Wen-Pei Sung and Ran Chen
Pages
1411-1415
DOI
10.4028/www.scientific.net/AMM.121-126.1411
Citation
X. J. Zhao, J. M. Lu, R. Luo, "Design of Shield Hydraulic Support with Variable Parameters", Applied Mechanics and Materials, Vols. 121-126, pp. 1411-1415, 2012
Online since
October 2011
Export
Price
$32.00
