Paper Title:
Design of the Test Rig for Whole Hydraulic Support
  Abstract

By the analysis of the development tendency and test standards requirements of high-level hydraulic support, this paper primarily determines the chief technical parameters and overall structure of the test rig for whole hydraulic support, and its 3-D model is built and assembly check is conducted by using SolidWorks. Then, the hydraulic control system and data acquisition system of the test rig are designed. In the end, the 3-D model of the test rig is imported into COSMOSWorks to accomplish the finite element analysis. According to analysis result, the strength of the test rig can meet the requirements, which ensures the design quality of the test rig for whole hydraulic support.
