Paper Title:
Analysis and Design of Z-Axis Supporting Plate of High-Speed High-Precision PCB CNC Driller
  Abstract

This paper is based on Abaqus finite element software platform and Tosca structure optimization software, with the purpose to improve the strength-to-weight ratio of Z-axis supporting plate. The writer adopts weight topology optimization to carry out finite element analysis, topology optimization analysis and verification to Z-axis supporting plate, thus getting the best material allocation solution. The modal frequency and dynamic performance of the product are greatly improved at the same time when ensuring the static precision of the product.

  Info
Periodical
Chapter
Chapter 6: Frontiers of Mechanical Engineering (1)
Edited by
Dongye Sun, Wen-Pei Sung and Ran Chen
Pages
3122-3126
DOI
10.4028/www.scientific.net/AMM.121-126.3122
Citation
L. He, M. L. Tang, H. Y. Wu, Y. L. Lei, Z. G. Wang, "Analysis and Design of Z-Axis Supporting Plate of High-Speed High-Precision PCB CNC Driller", Applied Mechanics and Materials, Vols. 121-126, pp. 3122-3126, 2012
Online since
October 2011
