Paper Title:
Processing Research for Unequal Diameter Machining Cylindrical Cam
  Abstract

For unequal diameter machining cylindrical cam profile based on double envelope principle, the practical profile equation and the profile machined by tool equation were given. The purpose of this study is explore new unequal diameter machining cylindrical cam method in the range of allowable error. According to the practical profile equation, the unequal diameter machining profile of cylindrical cam based on double envelope principle experiment were carried out. Considering the problem of accurate machining, three different diameter tool is used in the same cylindrical cam blank . And then, we used the software - Manufacturing Engineer XP to Program unequal diameter machining cylindrical cam Surface processing. The last, cylindrical cam surface was processed by CNC machining center.

  Info
Periodical
Chapter
Chapter 2: Manufacturing Technology and Machinery Automation
Edited by
Quanjie Gao
Pages
455-459
DOI
10.4028/www.scientific.net/AMM.127.455
Citation
C. Ma, B. Wang, W. B. Ma, B. Wang, R. L. Li, "Processing Research for Unequal Diameter Machining Cylindrical Cam", Applied Mechanics and Materials, Vol. 127, pp. 455-459, 2012
Online since
October 2011
Export
Price
$32.00
