Paper Title:
Significance Tests on Design Factors Affecting the Frequency Performance of Spherical Cymbal Transducer
  Abstract

Orthogonal experiment was used to optimize the design of spherical cymbal transducer. Through variance analysis of orthogonal experiment results, the primary and secondary order that each design factor affects the frequency performance of spherical cymbal transducer has been found. At the same time, the significant level of each design factor has been gained. Those factors which have highly significant or significant effects on the frequency performance of spherical cymbal transducer should be considered carefully during design spherical cymbal transducer, and those factors which have no significant effects can be ignored. In this way, the design factors were reduced, and the design complexity of spherical cymbal transducer was simplified.

  Info
Periodical
Chapter
Chapter 4: Fault Diagnose and Electronmechanical Control
Edited by
Zhixiang Hou
Pages
1015-1019
DOI
10.4028/www.scientific.net/AMM.128-129.1015
Citation
S. L. Wu, Q. Zhang, J. L. Xiong, "Significance Tests on Design Factors Affecting the Frequency Performance of Spherical Cymbal Transducer", Applied Mechanics and Materials, Vols. 128-129, pp. 1015-1019, 2012
Online since
October 2011
Export
Price
$32.00
