Paper Title:
Finite Element Analysis of the Helical Surface Cutting Tool
  Abstract

The screw motor is one kind of volume type power generator, the stator and the rotor is screw motor's core part. In this paper, cutting tool's internal stress and the distortion under the condition of milling inner helical curved surface was dissected with finite element method. Variable rule of feed engagement with changing of the processing parameter was discussed. The modal analysis of the special-purpose cutting tool was carried. To reduce the abnormal wear of special-purpose cutting tool in processing process and increase the special-purpose cutting life, the optimizing scheme was given. This research provides the theory reference for the optimized processing technological parameter.

  Info
Periodical
Chapter
Chapter 3: Functional Manufacturing and Information Technology
Edited by
Hun Guo, Taiyong Wang, Zeyu Weng, Weidong Jin, Shaoze Yan, Xuda Qin, Guofeng Wang, Qingjian Liu and Zijing Wang
Pages
289-292
DOI
10.4028/www.scientific.net/AMM.141.289
Citation
X. W. Sun, H. Wang, K. Wang, X. Feng, "Finite Element Analysis of the Helical Surface Cutting Tool", Applied Mechanics and Materials, Vol. 141, pp. 289-292, 2012
Online since
November 2011
Export
Price
$32.00
