Paper Title:
Research on the 3D Model’s Setup of Diamond Manufacturing Center with Fifteen Shafts
  Abstract

This paper describes the 3D model’s setup of diamond manufacturing center with fifteen shafts. It firstly introduces the concept of virtual design and virtual prototype, and common steps for building virtual prototype based on solidworks. Then it introduces the detailed steps of the diamond manufacturing center with fifteen shafts’ 3D model setup which includes parts and assembly. The paper also introduces the analysis of the diamond machine’s movement process. Finally, it gives the conclusion and further research. The research adopts the bottom to top principle and the top to bottom principle.

  Info
Periodical
Edited by
Kai Cheng, Yongxian Liu, Xipeng Xu and Hualong Xie
Pages
670-674
DOI
10.4028/www.scientific.net/AMM.16-19.670
Citation
S. Y. Yan, H. Wang, W. Liu, "Research on the 3D Model’s Setup of Diamond Manufacturing Center with Fifteen Shafts", Applied Mechanics and Materials, Vols. 16-19, pp. 670-674, 2009
