Paper Title:
Chord Error Closed-Loop Controlled NURBS Interpolator and Trajectory Planning
  Abstract

Focusing on the problem of NURBS curve interpolation in high speed manufacture, a new trajectory planning algorithm, which is suitable for chord error closed loop controlled interpolator is proposed. This tragjectory can determine accelerating, decelerating or maintenance last velocity in the next period via judging the braking distance. By the way of testing different calculating time under different CPU core, the real-time characteristic is validated. The simulation shows that chord error closed loop interpolator can automatically adjust the velocity to satisfying the precision demand, through calculating the curvature. In addition, it can assure that the maximal velocity and the acceleration were equal to the referenced parameters and machine runs with the dynamic characteristic of operator set completely.

  Info
Periodical
Edited by
Kai Cheng, Yongxian Liu, Xipeng Xu and Hualong Xie
Pages
925-929
DOI
10.4028/www.scientific.net/AMM.16-19.925
Citation
Y. Liu, J. Liu, "Chord Error Closed-Loop Controlled NURBS Interpolator and Trajectory Planning", Applied Mechanics and Materials, Vols. 16-19, pp. 925-929, 2009
Online since
October 2009
Authors
Export
Price
$32.00
