Paper Title:
The Research of Micromachined Gas Pendulum Accelerometer’s Structure
  Abstract

With the micromachining technology, two perpendicular cavities are formed on a silicon substrate, and two thermistors whose resistances are equal are placed parallel in each cavity. The nature convention of the gas is produced by the thermistors which are used as both the heater and the sensitive element in the hermetic cavity, and the acceleration can be measured with the temperature difference sensed by the thermistors. At last the test about the sensor shows when the value of acceleration is at the range of ±7g, the non-linearity is less than 0.62%FS.

  Info
Periodical
Edited by
Qi Luo
Pages
7-10
DOI
10.4028/www.scientific.net/AMM.20-23.7
Citation
Q. F. Zhao, F. X. Zhang, W. Zhang, P. Yue, "The Research of Micromachined Gas Pendulum Accelerometer’s Structure ", Applied Mechanics and Materials, Vols. 20-23, pp. 7-10, 2010
Online since
January 2010
Export
Price
$32.00
