Paper Title:
The Researchment for Tiny and Embedded Solid Error Check Algorithm of CAD Model
  Abstract

To solve many data error problems which produced by CAD model during the data conversion process in the environment of collaborative designment, based on CAD data quality standards, geometry and topology characteristics of CAD model, data errors such as tiny solid and embedded solid were described. By analyzing the geometry feature of model, the volume algorithm is proposed for the tiny solid. With the introduction non-linear theory, the check problem of the embedded solid is transformed into quadratic programming problem. Using VC++ and UG/Open API develop the error check system, and check algorithm is verified valid through typical instances. with supply a unified interface, check algorithm can be easily applied to various CAD platforms.

  Info
Periodical
Edited by
Dunwen Zuo, Hun Guo, Hongli Xu, Chun Su, Chunjie Liu and Weidong Jin
Pages
368-372
DOI
10.4028/www.scientific.net/AMM.33.368
Citation
C. Hu, M. H. Xu, "The Researchment for Tiny and Embedded Solid Error Check Algorithm of CAD Model ", Applied Mechanics and Materials, Vol. 33, pp. 368-372, 2010
Online since
October 2010
Authors
Export
Price
$32.00
