Paper Title:
The Design of Double-Helix Single-Screw Pump Based on PRO/E
  Abstract

Based on the unique merit of double-helix single-screw pump, its working principle is analyzed and its rolling bush and screw profile are designed in this paper. The 3D modeling and virtual assembly of double-helix Screw Pump are established based on Pro/E. The results showed that the multiphase pump could assembly with the design without interference. It provided the reference for optimal design and experimental prototype manufacturing.

  Info
Periodical
Edited by
Yi-Min Deng, Aibing Yu, Weihua Li and Di Zheng
Pages
1437-1441
DOI
10.4028/www.scientific.net/AMM.37-38.1437
Citation
X. B. Huang, G. Wen, "The Design of Double-Helix Single-Screw Pump Based on PRO/E", Applied Mechanics and Materials, Vols. 37-38, pp. 1437-1441, 2010
Online since
November 2010
