Paper Title:
MCU-Based Driven Design for the Electromagnetic Valve of the Repeated Impact Testing Machine
  Abstract

In view of repeated impact condition, developed a repeated impact test machine. This study focuses on using MCU (Micro Controller Unit) to control output of electromagnetic valve what is the core of the machine. The square wave signal , what is issued by AT89s52 and whose cycle and duty cycle can be adjusted, is used to control relay, thereby to control electromagnetic valve of the machine, and ultimately to realize multi-frequency repeated impact under the control of MCU system. A MCU control circuit system is designed at the aim of relay response, including control circuit of hardware, process design of software and anti-jamming design.

  Info
Periodical
Edited by
Long Chen, Yongkang Zhang, Aixing Feng, Zhenying Xu, Boquan Li and Han Shen
Pages
317-320
DOI
10.4028/www.scientific.net/AMM.43.317
Citation
X. D. Liu, J. G. He, G. Y. Fu, C. S. Li, "MCU-Based Driven Design for the Electromagnetic Valve of the Repeated Impact Testing Machine", Applied Mechanics and Materials, Vol. 43, pp. 317-320, 2011
Online since
December 2010
