Paper Title:
Structural Analysis of a Teat Cup Liner
  Abstract

This study attempts to analyze the structure of the thin-walled part in the teat cup liner for FEM by the finite-element method (FEM) and to determine the most suitable structure for it. For the first step, we prepared a specimen liner made from NBR (Acrylonitrile-Butadiene Rubber) and silicon rubber (made by ORION MACHINERY CO., LTD.) and conducted tensile and compression tests for mechanical scraping properties of rubber Data. We then analyzed the thin-walled part using SolidWorks Simulation (SolidWorks Corporation) for finite-element analysis in liner process from expression of milk into nipple massage.

  Info
Periodical
Edited by
Long Chen, Yongkang Zhang, Aixing Feng, Zhenying Xu, Boquan Li and Han Shen
Pages
675-677
DOI
10.4028/www.scientific.net/AMM.43.675
Citation
S. H. Adachi, L. M. Bao, O. Yamazaki, "Structural Analysis of a Teat Cup Liner", Applied Mechanics and Materials, Vol. 43, pp. 675-677, 2011
Online since
December 2010
Export
Price
$32.00
