Paper Title:
Design of Guide Rail in a Multi-Functional Open-Air Hydraulic Drill
  Abstract

As one of the main parts of a multi-functional open-air hydraulic drill, a guide rail is the benchmark of the power head movement. From the design experience, this paper discussed the performance requirements of the guide rail in a multi-functional open-air hydraulic drill, and studied its structural features, applications and force analysis. It has practical application value.

  Info
Periodical
Edited by
Ran Chen
Pages
1141-1145
DOI
10.4028/www.scientific.net/AMM.44-47.1141
Citation
Y. X. Luo, H. J. Wen, H. S. Li, "Design of Guide Rail in a Multi-Functional Open-Air Hydraulic Drill", Applied Mechanics and Materials, Vols. 44-47, pp. 1141-1145, 2011
Online since
December 2010
Export
Price
$32.00
