Paper Title:
Readout Circuit for Uncooled Pyroelectric IRFPA
  Abstract

A 320×240 readout circuit (ROIC) for the uncooled pyroelectric infrared detector was fabricated in the double-poly-double-metal (DPDM) N-well CMOS technology. Composed of X- and Y-shift register, column amplifier and correlated double sampling (CDS) circuit, the readout circuit integrated signal from the detector for frame time. It has the pitch of 50um and power dissipation of less than 50 mW. The circuit configuration, operation and testing result are described. Testing result indicates that the designed circuit meets with the requirement. Thermal images were obtained by the hybrid-integrated sensing array.

  Info
Periodical
Chapter
Energy Efficiency, Environment Ecology
Edited by
Aimin Yang, Jingguo Qu and Xilong Qu
Pages
284-288
DOI
10.4028/www.scientific.net/AMM.84-85.284
Citation
F. B. Lu, G. L. Lu, Y. S. Huang, X. H. Yuan, "Readout Circuit for Uncooled Pyroelectric IRFPA", Applied Mechanics and Materials, Vols. 84-85, pp. 284-288, 2011
