Paper Title:
Virtual Modeling and Finite Element Analysis of Flexspline Based on Solidworks
  Abstract

In harmonic gear mechanism, flexspline’ stress state have a direct impact on selecting wave generator as middle flexible components, this paper firstly simplify flexspline model, construct theory models, then simulate flexspline to compare and analyze in different wave generator, through this,we can select reasonable structure of wave generator from harmonic gear mechanism, provides a new method to design harmonic gear mechanism.

  Info
Periodical
Edited by
Zeyong Yin, Chengyu Jiang, Datong Qin, Peixin Qiao and Geng Liu
Pages
218-221
DOI
10.4028/www.scientific.net/AMM.86.218
Citation
R. Zhang, J. J. Yang, "Virtual Modeling and Finite Element Analysis of Flexspline Based on Solidworks", Applied Mechanics and Materials, Vol. 86, pp. 218-221, 2011
