Paper Title:
A Challenge to Design of a New Harmonic Drive Device
  Abstract

A new silk-hat type of harmonic drive device (HDD) with arc flexspline (FS) structure is developed. Loaded gear contact analysis (LGCA) and stress calculations are made for it with three-dimensional, finite element method (3D-FEM). Basic performances and strengths tests are also made. It is found that the new structure almost has the same performances and strength as the old one.

  Info
Periodical
Edited by
Zeyong Yin, Chengyu Jiang, Datong Qin, Peixin Qiao and Geng Liu
Pages
43-46
DOI
10.4028/www.scientific.net/AMM.86.43
Citation
S. T. Li, "A Challenge to Design of a New Harmonic Drive Device", Applied Mechanics and Materials, Vol. 86, pp. 43-46, 2011
Online since
August 2011
Authors
Export
Price
$32.00
