Paper Title:
A Model of Nonlinear Dynamic Modeling for Planetary Gear Transmission System with Backlash
  Abstract

The (4+N) DOFs (degrees of freedom) nonlinear dynamic model of the planetary gear transmission system has been established which include the horizontal displacement, vertical displacement of sun gear, eccentricity error excitation of the sun gear and planetary gear, and gear backlash. The nonlinear dynamic equations was dealt with non-dimensional. Non-dimensional relative displacement of sun gear with planet gears and planet gears with internal gear were solved by using the method of numerical integration. Load sharing coefficients of every planet gear was got by dealt with the result of dynamic equations. The differences of non-dimensional relative displacement and load sharing coefficient were contrasted.

  Info
Periodical
Edited by
Zeyong Yin, Chengyu Jiang, Datong Qin, Peixin Qiao and Geng Liu
Pages
510-513
DOI
10.4028/www.scientific.net/AMM.86.510
Citation
F. J. Li, R. P. Zhu, H. Y. Bao, X. Z. Li, "A Model of Nonlinear Dynamic Modeling for Planetary Gear Transmission System with Backlash", Applied Mechanics and Materials, Vol. 86, pp. 510-513, 2011
Online since
August 2011
