Paper Title:
The Design of the Tooth Shape Silence Chain
  Abstract

This article briefly introduces the structure of the tooth shape silence chain. The touch point of the roll pins separate when the chain goes around the sprocket gear. It deduces the dimensions of the offset angle α and the roll pin angle θ with mathematics method. This preface shows when the outer circular arc R≈0.5P, the fluctuation of the chain transmission speed is the least. When R=0.5P, We deduce the size of the roll pin by the value of α、θ、R and the ultimate tensile strength, then we can get the structure parameter of the chain plate hole by the method of geometrical construction.

  Info
Periodical
Edited by
Zeyong Yin, Chengyu Jiang, Datong Qin, Peixin Qiao and Geng Liu
Pages
594-597
DOI
10.4028/www.scientific.net/AMM.86.594
Citation
G. X. Yang, "The Design of the Tooth Shape Silence Chain", Applied Mechanics and Materials, Vol. 86, pp. 594-597, 2011
Online since
August 2011
