Paper Title:
Modeling and Analysis of Gear Driving System Based on the CATIA
  Abstract

In this paper, CATIA was used to establish the parameterized model for gear driving system of reducer. The Assembly Design workbench was used to complete the virtual assembly and the DMU Kinematics module was adopted to simulate the movement of gear pair. Finally, finite element analysis was conducted by using Analysis &Simulation module to simulate the actual working condition of gear driving system, which verified the rationality of parametric model and the accuracy of calculation , at the same time, provided the reference data for failure analysis.

  Info
Periodical
Edited by
Zeyong Yin, Chengyu Jiang, Datong Qin, Peixin Qiao and Geng Liu
Pages
700-703
DOI
10.4028/www.scientific.net/AMM.86.700
Citation
W. Cao, R. Wang, "Modeling and Analysis of Gear Driving System Based on the CATIA", Applied Mechanics and Materials, Vol. 86, pp. 700-703, 2011
Online since
August 2011
Authors
Export
Price
$32.00
