Paper Title:
Analysis on Deformation and Relieving of Spline in 1.5MW Wind Turbine Gearbox
  Abstract

For the sun gear shaft in wind turbine gearbox, the deformation will occur on the inner spline because of the thermal inserting of ring gear. So, the spline pair should be tooth relieved to avoid decrease of backlash and conflict of copulate parts. Based on the finite element analysis results, the deformation caused by the thermal inserting on the inner spline was calculated, and the theoretical tooth relieving curve was got. The practical thermal inserting deformation on the spline was measured. And the results indicate that the measuring deformations are in good consistency with the deformation calculated by finite element analysis method. The spline deformation and tooth relieving calculation method can provide a reference for the tooth relieving of the spline on long structure sun gear shaft in 1.5MW wind turbine gearbox.

  Info
Periodical
Edited by
Zeyong Yin, Chengyu Jiang, Datong Qin, Peixin Qiao and Geng Liu
Pages
908-913
DOI
10.4028/www.scientific.net/AMM.86.908
Citation
M. Zhang, L. Y. Zhang, Y. H. Bao, F. Gao, C. Wang, "Analysis on Deformation and Relieving of Spline in 1.5MW Wind Turbine Gearbox", Applied Mechanics and Materials, Vol. 86, pp. 908-913, 2011
Online since
August 2011
