Paper Title:
Structure Analysis on Gantry Machining Center and Characteristic Analysis of Rolling Guide Interface
  Abstract

Multi-point impulse tests, which could determine the transfer function of each point, were carried through on vertical and horizontal direction of sphericalguide-slider joint surface by DATRAN dynamic analyzer. Multi-point impulse tests could determine the transfer function of each point. In order to determine the single-DOF mode of the sphericalguide-slider joint surface, the top surface and one of the flanking surfaces of the sliding block were selected as test-object. When the amplitude of each point on the same surface is mainly equal with each other, the corresponding mode could be judged to be single-DOF mode. The experiment conclusion would be a foundation for the future dynamic simulation.

  Info
Periodical
Advanced Materials Research (Volumes 102-104)
Edited by
Guozhong Chai, Congda Lu and Donghui Wen
Pages
511-515
DOI
10.4028/www.scientific.net/AMR.102-104.511
Citation
Z. W. Zhang, C. Y. Jin, J. R. Zhang, "Structure Analysis on Gantry Machining Center and Characteristic Analysis of Rolling Guide Interface", Advanced Materials Research, Vols. 102-104, pp. 511-515, 2010
Online since
March 2010
