Paper Title:
Geometric Modeling for Five-Axis CNC Machining of Mold Surface with Flat-End Tool
  Abstract

This paper taken the flat-end tool and machined surface as a pair of mutually conjugate space contact tooth envelope surface and used the Frenet frame of differential geometry to describe the NC machining tool path in five-axis CNC machining of mold surface with flat-end tool. Thus the geometric model in five-axis CNC machining of mold surface with flat-end tool was established.

  Info
Periodical
Edited by
Qiusheng Yan, Jiabin Lu, Jun Wang and Hang Gao
Pages
41-45
DOI
10.4028/www.scientific.net/AMR.135.41
Citation
W. Q. Gao, B. Xie, Z. Y. Huang, C. T. Qing, "Geometric Modeling for Five-Axis CNC Machining of Mold Surface with Flat-End Tool", Advanced Materials Research, Vol. 135, pp. 41-45, 2010
Online since
October 2010
Export
Price
$32.00
