Paper Title:
The Research and Development of On-Line Inspection Work-Pieces Using CNC Machines
  Abstract

This document explains and demonstrates the module design and function of the on-line inspection system using the CNC machine. We designed the system for the five axes of the Shenyang Machine Tool Co. LTD’s CNC SSK-U6035 machine. The system could automatically shape and monitor the procedure, then according to the inspection outcomes align the machine and check the machine was correct. Using this system greatly improved the inspection speed and the measurement accuracy.

  Info
Periodical
Advanced Materials Research (Volumes 143-144)
Edited by
H. Wang, B.J. Zhang, X.Z. Liu, D.Z. Luo, S.B. Zhong
Pages
244-248
DOI
10.4028/www.scientific.net/AMR.143-144.244
Citation
Y. Q. Wang, W. D. Qu, "The Research and Development of On-Line Inspection Work-Pieces Using CNC Machines", Advanced Materials Research, Vols. 143-144, pp. 244-248, 2011
Online since
October 2010
Export
Price
$32.00
