Paper Title:
Modal Analysis about Direct-Drive Bi-Rotary Milling Head
  Abstract

Vibration characteristic of direct drive A/C bi-rotary milling head is been analyzed by finite element method (FEM), former four order vibration modes of the milling’s structure are given. The influence of the swing angle of the A-axis to the natural frequency of the milling head is analyzed. The natural frequencies when the milling head is working are interval values, the first order natural frequency is [120.48, 122.91], the second order natural frequency is [139.68, 142.08], the third order natural frequency is [328.68, 331.9], the fourth order natural frequency is [369.68, 372.45]. This computing provides technological support for design and improvement of this type of milling head.

  Info
Periodical
Advanced Materials Research (Volumes 154-155)
Edited by
Zhengyi Jiang, Xianghua Liu and Jinglong Bu
Pages
299-303
DOI
10.4028/www.scientific.net/AMR.154-155.299
Citation
M. Yan, L. Tang, P. Zheng, M. Y. Zhang, "Modal Analysis about Direct-Drive Bi-Rotary Milling Head", Advanced Materials Research, Vols. 154-155, pp. 299-303, 2011
Online since
October 2010
