Paper Title:
Time-Domain Characteristics Analysis of Penetration Arc Sound Signal in MIG Welding
  Abstract

Many important time-domain characteristic parameters are extracted through the short-time analysis of arc sound signal in MIG butt welding with spray transfer, which can be used for the diagnosis on the weld penetration status. And the short-time autocorrelation function and short-time average amplitude difference function are adopted to pitch estimation. The analysis results show that the penetration status can be accurately recognized via the short-time energy, average magnitude, average zero-crossing and zero-to-energy and so on. Meanwhile, the pitch estimation of arc sound signal in experiments is at 220 points, that is 5 ms or 200 Hz in cycle. The methods and results provide a foundation for the diagnosis on penetration based on analysis of arc sound signal and have great theoretical meaning and practical value.

  Info
Periodical
Advanced Materials Research (Volumes 154-155)
Edited by
Zhengyi Jiang, Xianghua Liu and Jinglong Bu
Pages
453-456
DOI
10.4028/www.scientific.net/AMR.154-155.453
Citation
L. J. Liu, Q. Wang, L. Hu, "Time-Domain Characteristics Analysis of Penetration Arc Sound Signal in MIG Welding", Advanced Materials Research, Vols. 154-155, pp. 453-456, 2011
Online since
October 2010
