Paper Title:
Parametric Design of Face Milling Cutter Based on UG Template Model
  Abstract

UG template model-based parametric design method plays an important role in improving face milling cutter design efficiency and ensuring design accuracy. Three kinds of parameter design method are described in this paper. Parametric design of series for face milling cutters is completed with UG software and UG template model, moreover, user menu and an interactive window are customized, which improves design efficiency and accuracy of face milling cutter. Meanwhile, this study can provide reference for more model design and functional development.

  Info
Periodical
Edited by
Chengyong Wang, Ning He, Ming Chen and Chuanzhen Huang
Pages
336-339
DOI
10.4028/www.scientific.net/AMR.188.336
Citation
S. Y. Ji, X. L. Liu, D. L. Ma, Y. P. Ding, J. Wu, "Parametric Design of Face Milling Cutter Based on UG Template Model", Advanced Materials Research, Vol. 188, pp. 336-339, 2011
Online since
March 2011
Export
Price
$32.00
