Analysis of Cutter Offset Function in NC Lathe and its Applications
  Abstract

The concept and usage of cutter offset compensation was introduced, and the cutter wear compensation and cutter radius compensation were calculated. The processing error produced by tool corner radius was analyzed, and the function, application occasion and usage of radius compensation in CNC lathe cutter is discussed, which has special significance for the accurate machining. The examples are given to illustrate how to using methods and skills in NC turning programming reasonably.
