Paper Title:
Characteristics of Rotary Draw-Bent Tubes for the Hydroforming
  Abstract

Hydroformed parts have higher dimensional accuracy, structural strength, and dimensional repeatability. The pre-bending process is an important process for the successful hydroforming in the case where the perimeter of the blank is nearly the same as that of final product. At initial pre-bending stage, the variations of wall thickness and cross-section have effects on the accuracy of final products and quality. Because of a relatively excellent productive velocity, geometric size precision and reliance of product qualities, rotary draw bending is widely used. This study shows the bendability such as cross-section ovality, springback ratio and thickness variation in the various conditions of materials.

  Info
Periodical
Edited by
Zhang Yushu
Pages
320-324
DOI
10.4028/www.scientific.net/AMR.213.320
Citation
B. D. Joo, J. H. Jang, H. J. Lee, Y. H. Moon, "Characteristics of Rotary Draw-Bent Tubes for the Hydroforming", Advanced Materials Research, Vol. 213, pp. 320-324, 2011
Online since
February 2011
Export
Price
$32.00
