Paper Title:
Finite Element Modeling of Burr Formation in Metal Cutting with a Backup Material
  Abstract

2D finite element model with the same material for backup to minimize the burr size was developed to investigate mechanism of burr formation and burr minimization. The flowstress of the workpiece and backup material are taken as a function of strain, strain-rate and temperature. Temperature-dependent material properties are also considered. The Cockroft-Latham damage criterion has been adopted to simulate ductile fracture. The crack initiation and propagation is simulated by deleting the mesh element. The result shows putting a backup material behind the edge of the workpiece is an effective way to minimize the burr size. The effects of cutting condition, temperature and different backup material properties on the burr formation and burr size can be investigated using the developed finite element model. This model could be useful in the search for optimal tool geometry and cutting condition for burr minimization and for the modeling of a burr formation mechanism.

  Info
Periodical
Advanced Materials Research (Volumes 24-25)
Edited by
Hang Gao, Zhuji Jin and Yannian Rui
Pages
71-76
DOI
10.4028/www.scientific.net/AMR.24-25.71
Citation
W. J. Deng, W. Xia, L. S. Lu, Y. Tang, "Finite Element Modeling of Burr Formation in Metal Cutting with a Backup Material", Advanced Materials Research, Vols. 24-25, pp. 71-76, 2007
Online since
September 2007
Export
Price
$32.00
