Paper Title:
The Design of C-Language Graphics Library Functions Based on JRD320240B
  Abstract

The paper mainly introduces C-language graphics library functions based on JRD320240B. For example, it can display Chinese word, character list, painting line and picture on any point of the LCD. And gives the corresponding hardware interface circuit, software flow diagram of C8051F020 and JRD320240B.The paper has reference value in practical application.

  Info
Periodical
Advanced Materials Research (Volumes 271-273)
Edited by
Junqiao Xiong
Pages
417-422
DOI
10.4028/www.scientific.net/AMR.271-273.417
Citation
J. T. Zhang, X. M. Zhang, Z. G. Yan, "The Design of C-Language Graphics Library Functions Based on JRD320240B", Advanced Materials Research, Vols. 271-273, pp. 417-422, 2011
Online since
July 2011
Keywords
Export
Price
$32.00
