Paper Title:
Exploration of Several Difficult Croblems in Compiling Drawing Used AutoCAD
  Abstract

It discourses the methods and procedures of drawing axonometric and intersection while AutoCAD is applied to the complication of drawing teaching material; discusses the techniques of screen-capture and the application of BetterWMF when AutoCAD is inserted into Word Documents. All of the above methods and techniques have great utility value.

  Info
Periodical
Advanced Materials Research (Volumes 271-273)
Edited by
Junqiao Xiong
Pages
904-910
DOI
10.4028/www.scientific.net/AMR.271-273.904
Citation
H. Z. Luo, "Exploration of Several Difficult Croblems in Compiling Drawing Used AutoCAD", Advanced Materials Research, Vols. 271-273, pp. 904-910, 2011
Online since
July 2011
