Paper Title:
Springback Simulation in Stretch Bending of Aluminum Extrusions Using Static Implicit and Dynamic Explicit FE Codes
  Abstract

First stretch bending process of aluminium extrusions given by Norwegian scholars is simulated by using revised model proposed in the paper. That maximum die force calculated is closer to experiment than Norwegian scholars’ one demonstrates that the revised model is rather accurate in forming simulation and lays the foundation for later springback simulation. Then springback is simulated by using dynamic explicit and static implicit FE codes, respectively. The influences on cross-sectional distortion and springback of two codes are compared. It is shown that dynamic explicit FE code can predict cross-sectional distortion accurately and static implicit FE code overestimates it. Neither of two codes can predict springback accurately. Dynamic explicit FE code overestimates it and static implicit one FE code underestimates it.

  Info
Periodical
Advanced Materials Research (Volumes 295-297)
Chapter
Chapter 2: Metal Casting Processes and Equipment
Edited by
Pengcheng Wang, Liqun Ai, Yungang Li, Xiaoming Sang and Jinglong Bu
Pages
1606-1612
DOI
10.4028/www.scientific.net/AMR.295-297.1606
Citation
X. Q. Li, H. Li, D. S. Li, "Springback Simulation in Stretch Bending of Aluminum Extrusions Using Static Implicit and Dynamic Explicit FE Codes", Advanced Materials Research, Vols. 295-297, pp. 1606-1612, 2011
Online since
July 2011
