Paper Title:
The Image Process Technology of Micro-Detection for Jet-Pan Based on CCD
  Abstract

The jet-pan is a key part of jet-pan servo valve, working performance of the servo valve is directly affected by the machining quality. This paper has realized the high precision measurement on dimension and position accuracy of the jet-pan through the research on CCD optical micro-detection technology. The result of image processing will affect the measuring accuracy directly during the detection, so this paper will put emphasis on discussing the image processing algorithm in the detection of the jet-pan. Through a series of algorithmic combination, this paper will achieve the image process and finally obtain the result.

  Info
Periodical
Edited by
Guanglin Wang, Huifeng Wang, Jun Liu and Xilin Zhu
Pages
31-36
DOI
10.4028/www.scientific.net/AMR.305.31
Citation
D. X. Shao, J. Li, R. Lin, G. L. Wang, "The Image Process Technology of Micro-Detection for Jet-Pan Based on CCD", Advanced Materials Research, Vol. 305, pp. 31-36, 2011
Online since
July 2011
