Paper Title:
Rigid-Flexible Coupled Modeling and Simulation Analysis of Printing Cylinder Based on ANSYS
  Abstract

In order to analyze the influence on the printing graphics from the deformation of the printing cylinders and blankets, in this paper, offset printing unit was as the research object, the three-dimensional assembly model of printing cylinders was established by using SolidWorks , the model was imported into finite element software ANSYS, by using ANSYS nonlinear contact calculated functionality, the face-to-face contact of impression surface between plate cylinder and blanket cylinder, blanket cylinder and impression cylinder were established, the stress and strain distribution of blanket were obtained, and the elongation value of circumferential and radial direction of blanket were got, the dot enlargement value was received by simulation analysis.

  Info
Periodical
Advanced Materials Research (Volumes 308-310)
Chapter
Advanced CAE Technique
Edited by
Jian Gao
Pages
2418-2421
DOI
10.4028/www.scientific.net/AMR.308-310.2418
Citation
J. Z. Guo, J. P. Yang, T. T. Cai, "Rigid-Flexible Coupled Modeling and Simulation Analysis of Printing Cylinder Based on ANSYS", Advanced Materials Research, Vols. 308-310, pp. 2418-2421, 2011
Online since
August 2011
