Paper Title:
Warpage and Structural Analysis of Automotive Trim Based on FFD and CAE in Plastic Injection Molding
  Abstract

In this study, the automotive glove-box-cover was decided as a model, which was assembled on the instrument panel. The material of the cover was Kingfa Sci & Tech Co Ltd, PP+EPDM+20%Talc co-polymer. Firstly, the effects of the process parameters on warpage were examined using FFD. To look for the warpage values, the CAE software Moldflow was used. The significant parameters were found out. Secondly, to determine the distortions of the special points over the top surface of the glove-box-cover, the software Ansys10.0 was used. The structural analyses of the glove-box-cover with different thickness were done in order to determine the performance, and the suggested thickness of the cover was pointed out. At the same time, the strongest and weakest points were found out.

  Info
Periodical
Advanced Materials Research (Volumes 314-316)
Chapter
Material Design of Computer Aided
Edited by
Jian Gao
Pages
1282-1286
DOI
10.4028/www.scientific.net/AMR.314-316.1282
Citation
W. Guo, H. J. Mao, Q. Xu, "Warpage and Structural Analysis of Automotive Trim Based on FFD and CAE in Plastic Injection Molding", Advanced Materials Research, Vols. 314-316, pp. 1282-1286, 2011
Online since
August 2011
