Paper Title:
Research and Development of Woodworking Curved Jaw CAM
  Abstract

CAM (Computer Aided Manufacturing) software, one of important aid means of numerical control machining, improves the automatic level of processing with its application in numerical control machining industry. According to the character of woodworking curved jaw (WCJ), limitations of secondary development with existing CAM software were analyzed, and the advantages and basic principles of CAM which was independent development were introduced. In this CAM, dxf files as graphic information input for WCJ. Finally, CAM for WCJ was developed with VC++ and OpenGL.

  Info
Periodical
Advanced Materials Research (Volumes 314-316)
Chapter
CAM/CAE
Edited by
Jian Gao
Pages
1542-1545
DOI
10.4028/www.scientific.net/AMR.314-316.1542
Citation
L. J. Chen, X. J. Zou, B. B. Chen, J. Li, "Research and Development of Woodworking Curved Jaw CAM", Advanced Materials Research, Vols. 314-316, pp. 1542-1545, 2011
Online since
August 2011
