Paper Title:
Modeling and Simulation on Fluid Dynamic Depth-Setting TUV Based on FLUENT
  Abstract

The prerequisite factors for the simulation and controlling of underwater vehicles are hydrodynamic coefficients, which we must measure accurately. In this paper, we took a complex shape remotely operated vehicle as the test model, and figured out the important coefficients that can be applicable for the open-shelf depth-setting TUV through a series of hydrodynamic tests. In order to boost the reliability of a depth-setting TUV system, we carry out numerical simulation and hydrodynamics method on the body of the TUV through the Dynamic Analysis of a single rudder .Comparing with empirical equation, the method has be predicted a high accuracy in hydrodynamic characteristic prediction of depth-setting towed vehicle . After changing the experiment environment of the TUV as possible as we can, a suitability algorithm can be used on the distribute system. And then, the pre-design and later validation of TUV with the conclusion of the simulation based on FLUENT which contribute to shorter calculating period and lower economy could show better depth-setting consequent. The paper draw the Process of the Dynamic Depth-setting TUV for three parts including simulation of the rubber , algorithm experiment of the body and the experiment on TUV.

  Info
Periodical
Advanced Materials Research (Volumes 314-316)
Chapter
CAM/CAE
Edited by
Jian Gao
Pages
1676-1681
DOI
10.4028/www.scientific.net/AMR.314-316.1676
Citation
G. H. Xu, X. Shen, K. Yu, "Modeling and Simulation on Fluid Dynamic Depth-Setting TUV Based on FLUENT", Advanced Materials Research, Vols. 314-316, pp. 1676-1681, 2011
Online since
August 2011
