Paper Title:
Finite Element Analysis of High - Pressure Grinding Mill
  Abstract

The stress distribution of the high - pressure grinding roller is an important index of the grinding mill design. A simulation model of high - pressure grinding roller is created by means of finite element method (FEM), utilizing the FEM software ANSYS. At first, the paper calculated the pressure of the high - pressure grinding roller by the grinding materiel mathematical model. Secondly, a physical model is set up material characteristics is defined and the areas are meshed, then the border conditions are established, finally loading and solving are made. The result of the FEM simulation indicated the mathematical model of the grinding materiel is rational.

  Info
Periodical
Advanced Materials Research (Volumes 314-316)
Chapter
Materials Processing Technology
Edited by
Jian Gao
Pages
675-681
DOI
10.4028/www.scientific.net/AMR.314-316.675
Citation
Y. Liu, J. S. Li, "Finite Element Analysis of High - Pressure Grinding Mill", Advanced Materials Research, Vols. 314-316, pp. 675-681, 2011
Online since
August 2011
