Paper Title:
Study on the Reverse Designing for Water Cavity Model of Engine’s Cylinder Head
  Abstract

The water cavity model of engine’s cylinder head is reconstructed by CAD through slicing method. The reverse design methods which are used for complex interior structure’s surface are explored based on slicing method and using software such as Imageware and UG, through modeling the water cavity. The technologies of reverse design such as the measure method of points cloud, points cloud data treatment, curve fitting, fitting error analysis, surface reconstructive and solid modeling are studied. The reverse methods for complex surface are put forward which are based on blocks and features of model. Through the practice of reversing design for cylinder head water cavity model, it is proven that the complex inner cavity components can be reversed by slicing method. The methods can be referenced for similar reverse design.

  Info
Periodical
Advanced Materials Research (Volumes 328-330)
Chapter
Chapter 1: Manufacturing Technology and Processing
Edited by
Liangchi Zhang, Chunliang Zhang and Zichen Chen
Pages
71-74
DOI
10.4028/www.scientific.net/AMR.328-330.71
Citation
M. Chen, X. X. Liu, J. P. Tian, "Study on the Reverse Designing for Water Cavity Model of Engine’s Cylinder Head", Advanced Materials Research, Vols. 328-330, pp. 71-74, 2011
Online since
September 2011
