Paper Title:
Research and Design of Box-Taking Mechanism in Automatic Cartoner
  Abstract

Box-taking mechanism is an important part of automatic cartoner, it also is a “bottleneck” in automatic cartoner. After analyzing the process of box-taking and the key movements for automatic cartoner, designed a new kind of box-taking mechanism with double cam five-bar combined mechanism. Combining five-bar mechanism and cam advantages, the mechanism can be realized the trajectory with the demand of velocity and gesture. The detailed and interchangeable gas circuit also be designed, which reduced the complexity of replacing the seal rings. Practical result shows that the mechanism could execute the box-taking gesture quickly and smoothly.

  Info
Periodical
Advanced Materials Research (Volumes 328-330)
Chapter
Chapter 1: Manufacturing Technology and Processing
Edited by
Liangchi Zhang, Chunliang Zhang and Zichen Chen
Pages
743-746
DOI
10.4028/www.scientific.net/AMR.328-330.743
Citation
J. J. Cao, L. Li, X. H. Tian, "Research and Design of Box-Taking Mechanism in Automatic Cartoner", Advanced Materials Research, Vols. 328-330, pp. 743-746, 2011
Online since
September 2011
