Paper Title:
Finite Element Analysis of Pump Casing for Triplex Plunger Pump Based on Abaqus
  Abstract

The force of pump casing for triplex plunger was very complex, as well as the loads varied with the angle of crankshaft rotation. Using VB programming software obtained the load of pump casing anywhere, then 3D models of pump casing of triplex plunger pump have been created by utilizing Pro/E, and strength calculation of the pump casing was analyzed by utilizing Abaqus software in six different load conditions. The results indicated that the dangerous cross section and the stress distribution have been found and the maximum stress of the pump casing was 297.3 MPa, which was less than the limit of yielding strength but met the overall strength of pump casing. This research was significant for the reliability evaluation and the design improvement of the pump casing.

  Info
Periodical
Chapter
Chapter 2: Modeling, Analysis and Simulation of Manufacturing Processes
Edited by
Prasad Yarlagadda, Yun-Hae Kim, Zhijiu Ai and Xiaodong Zhang
Pages
219-224
DOI
10.4028/www.scientific.net/AMR.337.219
Citation
X. He, C. J. Huang, Q. Y. Liu, Y. Liu, J. Y. Tian, "Finite Element Analysis of Pump Casing for Triplex Plunger Pump Based on Abaqus", Advanced Materials Research, Vol. 337, pp. 219-224, 2011
