Paper Title:
Error Inspection for Turbine Vane Based on Reverse Engineering
  Abstract

An error inspection method based on 3D laser scanning measurement is proposed for the purpose of achieving field rapid inspection of turbine vane surface. The 3D model of vane is reconstructed by using the data of form drawing in CATIA. By using handy laser scanner, the point cloud data is obtained from the wood pattern of vane, which is processed in Geomagic Qualify. After registration of vane solid model and point cloud data, the vane surface is rapidly inspected by analyzing 3D error and comparing cross-sectional data.

  Info
Periodical
Chapter
Chapter 2: CAD/CAM/CAE
Edited by
Xiaodong Zhang, Zhijiu Ai, Prasad Yarlagadda and Yun-Hae Kim
Pages
335-338
DOI
10.4028/www.scientific.net/AMR.338.335
Citation
G. Tong, Y. Z. Li, D. W. Wu, X. G. Han, "Error Inspection for Turbine Vane Based on Reverse Engineering", Advanced Materials Research, Vol. 338, pp. 335-338, 2011
Online since
September 2011
