Paper Title:
Finite Element Analysis of Ring-Plate Indexing Cam Mechanism Contact Stress Based on MATLAB and ANSYS
  Abstract

This paper is aimed to analyse contact stress of ring-plate indexing cam mechanism which is a new type of indexing cam mechanism. A contact finite element model of the cam and the pin gear is established with the commercial software of MATLAB and ANSYS. With the finite element analysis, the contact stress of the cam and the pin gear is predicted in one motion cycle. On the basis of the finite element analysis, the force and the position of maximum stress are obtained. The conclusion proposed here is reliable to instruct the design of ring-plate indexing cam mechanism.

  Info
Periodical
Advanced Materials Research (Volumes 383-390)
Chapter
Chapter 10: Materials Forming
Edited by
Wu Fan
Pages
2862-2867
DOI
10.4028/www.scientific.net/AMR.383-390.2862
Citation
Y. Q. Li, M. T. Liu, G. C. Tian, "Finite Element Analysis of Ring-Plate Indexing Cam Mechanism Contact Stress Based on MATLAB and ANSYS", Advanced Materials Research, Vols. 383-390, pp. 2862-2867, 2012
Online since
November 2011
