Paper Title:
Investigation of Strength in G4-73 Type Centrifugal Fan Impeller
  Abstract

For the large centrifugal fan impeller, its working condition generally is bad, and its geometry generally is complex. So its displacements and stresses distribution are also complex. In this paper, we can obtain the fan impeller’s displacements and stresses distribution accurately through numerical simulation in G4-73 type centrifugal fan impeller using the finite element method software ANSYS. The calculation result shows that the maximum total displacement of the impeller is m, it occurs on the position of the half of the blade near the outlet of the impeller; and the maximum equivalent stress of the impeller is 193 MPa, it occurs on the contacted position of the blade and the shroud near inlet of the impeller. Furthermore, check the impeller strength, the result shows that the strength of the impeller can meet the requirement.

  Info
Periodical
Advanced Materials Research (Volumes 383-390)
Chapter
Chapter 22: Computer-Aided Engineering in Manufacturing
Edited by
Wu Fan
Pages
5669-5673
DOI
10.4028/www.scientific.net/AMR.383-390.5669
Citation
S. L. Wang, Z. Sun, Z. R. Wu, "Investigation of Strength in G4-73 Type Centrifugal Fan Impeller", Advanced Materials Research, Vols. 383-390, pp. 5669-5673, 2012
Online since
November 2011
