Paper Title:
Implementation of a DirectDrive Technology Realization DC-Coupled Output on Video-Output Circuits
  Abstract

An AC-coupled output includes a series capacitor, while a DC-coupled output does not. This article explains the reasons for choosing either an AC-coupled or a DC-coupled video output. Maxim's DirectDrive video technology eliminates large output coupling capacitors and sets the output video black level near ground, which has the characteristics of an AC-coupled connection but the simplicity of a DC-coupled connection, is introduced. The working principle of Capacitive Charge Pump, is introduced too. Take the case of MAX9532 analyses the main choice of the components and parts in peripheral circuit, it has listed the precautions in the circuit design.

  Info
Periodical
Advanced Materials Research (Volumes 383-390)
Chapter
Chapter 1: Computer-Aided Manufacturing
Edited by
Wu Fan
Pages
724-726
DOI
10.4028/www.scientific.net/AMR.383-390.724
Citation
C. X. Lv, "Implementation of a DirectDrive Technology Realization DC-Coupled Output on Video-Output Circuits", Advanced Materials Research, Vols. 383-390, pp. 724-726, 2012
Online since
November 2011
