Paper Title:
Research on Product Model Based on Object-Oriented Method
  Abstract

A product structure model for Rapid Product Design (RPD) is discussed. It is composed of Assembly Topology Tree (ATT) that describes the assembly relation between parts and the Part Topology Tree (PTT) that describe the geometry relation in a part, and it explains the constraint relations and the selection conditions between the components and parts. Product model class and its subclasses are built by Object-Oriented method to describe the structure and relation of a product and its components. At last an instance of the product structure model is introduced.

  Info
Periodical
Advanced Materials Research (Volumes 44-46)
Edited by
Z.Y. Shen, M.N. James, W.D. Li, and Y.X. Zhao
Pages
601-606
DOI
10.4028/www.scientific.net/AMR.44-46.601
Citation
X. M. Qian, D. B. Tang, "Research on Product Model Based on Object-Oriented Method", Advanced Materials Research, Vols. 44-46, pp. 601-606, 2008
Online since
June 2008
Export
Price
$32.00
Share
