Paper Title:
Effect of Brazing Temperature on the Microstructure and Property of Vacuum Brazed WC-Co and Carbon Steel Joint
  Abstract

The effect of brazing temperature on the properties of brazed joints between WC-Co hard alloy and SAE1045 carbon steel using Cu and ASTM C52100 bronze metal as insert fillers were investigated. A vacuum brazing furnace was employed to conduct the experiment with different sets of operational parameters (brazing temperature, bonding time and filler) were used. The experimental result shows that Fe-Co-Cu alloy layer was formed at the WC-Co/Cu filler interface. With increased brazing temperature and bonding time, the thickness of the Fe-Co-Cu layer increases. From the shear test, the maximum shear strength is 320±10 MPa for the joint brazed at 1140°C for 15 min using Cu filler. The shear strength of WC-Co/C52100/SAE1045 brazed joints was better than WC-Co/Cu/SAE1045 brazed joints. The increase of bonding time of WC-Co/C52100/SAE1045 joints improved the shear strength slightly.

  Info
Periodical
Advanced Materials Research (Volumes 47-50)
Edited by
Alan K.T. Lau, J. Lu, Vijay K. Varadan, F.K. Chang, J.P. Tu and P.M. Lam
Pages
682-685
DOI
10.4028/www.scientific.net/AMR.47-50.682
Citation
L. H. Chiu, H. F. Wang, C. P. Huang, C. T. Hsu, T. C. Chen, "Effect of Brazing Temperature on the Microstructure and Property of Vacuum Brazed WC-Co and Carbon Steel Joint", Advanced Materials Research, Vols. 47-50, pp. 682-685, 2008
Online since
June 2008
