Paper Title:
Development and Experimental Study of Multi-Axis Micro-EDM Machine Tool for Small-Hole Based on Linear Motor
  Abstract

A multi-axis micro-EDM machine tool for small hole is developed. It mainly includes marble base, precision servo and linear-motor platforms, RC pulse power supply, CCD microscope and so on. Superiority of linear motor used on the Z axis is analyzed. Primary experiments, in which small electrodes with different materials are used to machine 3mm thickness TC4, are carried out. Histograms of open-circuit voltage and capacitance to machining efficiency and electrode relative wear and small-hole samples are given. Influence rules of open-circuit voltage and capacitance to machining efficiency and electrode relative wear are analyzed according to experimental results.

  Info
Periodical
Advanced Materials Research (Volumes 69-70)
Edited by
Julong Yuan, Shiming Ji, Donghui Wen and Ming Chen
Pages
74-78
DOI
10.4028/www.scientific.net/AMR.69-70.74
Citation
Z. L. Wang, M. S. Li, G. X. Chi, Y. K. Wang, W. S. Zhao, "Development and Experimental Study of Multi-Axis Micro-EDM Machine Tool for Small-Hole Based on Linear Motor", Advanced Materials Research, Vols. 69-70, pp. 74-78, 2009
Online since
May 2009
